Avallon APAC120S User's Guide

USER’S GUIDE PORTABLE AIR CONDITIONER MODEL- APAC120S Installation, Operation, and Maintenance for your portable air conditioner www.avallon.co

7 After you have installed the exhaust hose and window kit, you can plug in your portable air conditione

Avallon Portable Air Conditioner 8 Your portable air conditioner is designed to exhaust condensate water that is collected from the air. This wa

9 Drainage Options Your Avallon portable air conditioner comes with several different options to drain water accumulated during operation. The mos

Avallon Portable Air Conditioner 10 1. Connect the included water line to the unit. You will need to attach the quick connect adapter on the e

11 Remote Control Overview 1) Remove the cover on the back of the remote control. 2) Insert the batteries with the (+) and (-

Avallon Portable Air Conditioner 12 Remote Control LCD Indicators Indicators Transmitter Appears when the Power or Timer button is signaling th

13 Operating the Remote Control Use the Power button to turn the portable air conditioner on and off. By default when you first use the power but

Avallon Portable Air Conditioner 14 Fan Only mode is used to circulate the air in your room. No temperature setting is needed. The front panel li

15 The timer can be used to either turn the unit on or off after a number of elapsed hours. The timer is adjustable between 1-24 hours in one hour i

Avallon Portable Air Conditioner 16 Energy Saving Guide Read and follow the guide below to get the best performance and efficiency from your port

Important Safety Information Improper handling can cause serious damage to the appliance and/or to the user. This portable air conditioner is not

17 Maintenance Clean the air conditioner and filters regularly to maximize performance and efficiency, and prolong the unit’s life. Be sure to always

Avallon Portable Air Conditioner 18 Troubleshooting Follow the troubleshooting guide below to resolve common issues. Issue Possible Cause Solutio

19 Troubleshooting continued Issue Possible Cause Solution My air conditioner is not cooling at all Unit is not operating in cooling mode Set the un

Avallon Portable Air Conditioner 20 Specifications Description of product Portable Air Conditioner Model APAC120S Voltage/Frequency 115V/60Hz Inp

WHAT IS COVERED: One Year Parts and Labor: For one year from the date of original retail purchase, Avallon will repair or replace any part free of ch

AVALLON GLOBAL, LLC 3736 Bee Cave Rd. STE 1 #188 West Lake Hills, TX 78746 Toll Free: 1-866-471-7427 Web: http://www.a

Avallon Portable Air Conditioner ii Table of Contents IMPORTANT SAFETY INFORMATION ...

1 Introduction Thank you for purchasing your Avallon portable air conditioner. Avallon is dedicated to developing products that will enhance your li

Avallon Portable Air Conditioner 2 Parts Identification Back View Front View Pre-filter Air Intake Air Intake Exhaust Outlet Power Cord Drain Po

3 Window Kit Installation Instructions You must vent your portable air conditioner when running it in cooling mode or heat mode (certain models). Yo

Avallon Portable Air Conditioner 4 Installing the grated adapter 1. Insert the round grated ada

5  Installing the window plates 3. Open your window and place the window kit with grooved side faci

Avallon Portable Air Conditioner 6 Attaching the duct connectors to the exhaust hose A.B. 5. Atta
